Chevrolet Equinox Repair Manual

Haynes Repair Manual for Chevrolet Equinox 2018 - 2022.

This manual's year range represents the years of coverage available when the manual was written. The vehicle or machine's production years may extend beyond these dates.

Sub-Model: Mk III

Engines:
1.5 Turbo Gas (LYX)
1.6 Turbo Diesel (LH7)
2.0 Gas (LTG)

Table of Contents
Jacking and Lifting – p.5
Lubricants, Fluids, and Tire Pressures – p.6
Troubleshooting – p.6
Chapter 1: Routine Maintenance and Servicing – p.7
Chapter 2A: 1.5L Gasoline Engine Repair Procedures – p.21
Chapter 2B: 2.0L Gasoline Engine Repair Procedures – p.43
Chapter 3: Cooling, Heating, and Air Conditioning Systems – p.65
Chapter 4A: Fuel and Exhaust Systems – 1.5L Engine – p.85
Chapter 4B: Fuel and Exhaust Systems – 2.0L Engine – p.107
Chapter 4C: Emission Control Systems – p.129
Chapter 5A: Starting and Charging – p.135
Chapter 5B: Ignition System – p.143
Chapter 6A: Automatic Transmission – p.145
Chapter 6B: Power Transfer Unit (PTU) – p.158
Chapter 7: Driveshaft, Halfshafts, and Axles – p.163
Chapter 8: Braking System – p.177
Chapter 9: Suspension and Steering – p.197
Chapter 10: Bodywork and Fittings – p.215
Chapter 11: Body Electrical System – p.249
Chapter 12: Wiring Diagrams – p.277
Index – p.278
